Product description

The Wilkerson M30-08-G00 is a genuine OEM 1in NPT coalescing filter engineered to remove oil aerosols, water droplets, and sub-micronic particles from a compressed air system, protecting sensitive downstream pneumatic equipment. Using mechanical coalescing filtration, the filter media collects fine liquid particles that merge into larger droplets and drain away, while an anti-reentrainment barrier prevents contaminants from re-entering the airstream. Rated for up to 200 PSI and equipped with a durable metal bowl with sight gauge and manual petcock drain, this coalescing filter/oil separator element is a direct OEM replacement for the 1in port position in Champion and Wilkerson-style modular FRL (Filter-Regulator-Lubricator) compressed air treatment systems.

Product highlights

• Coalescing Filtration: Removes oil aerosols, water droplets, and sub-micronic particles from compressed air.
• 1in NPT, 200 PSI Rated: Sized for high-flow compressed air system oil separation.
• Anti-Reentrainment Barrier: Prevents collected contaminants from returning to the airstream.
• Metal Bowl with Sight Gauge: Durable construction with visible contamination level monitoring.
• Direct OEM Fit: Replaces the oil separator/coalescing filter position in Champion/Wilkerson FRL systems.

Specs

• Manufacturer: Champion Pneumatic / Wilkerson (Gardner Denver)
• Manufacturer Part Number: CM30-08-G00 (Wilkerson M30-08-G00)
• Component Type: Coalescing Filter / Oil Separator
• Pipe Size: 1in NPT
• Maximum Pressure: 200 PSI
• Maximum Temperature: 150 degrees F
• Bowl Type: Metal Bowl with Sight Gauge
• Drain Type: Manual Petcock
• Body Material: Zinc
• Dimensions: 4.6in W x 10.5in H

Direct replacement models

GF30-08-G00, M30-08-G00, Wilkerson M30-08-G00

You will receive the same product or an OEM-Equivalent that meets the highest standard of the OEM with warranty that will be a direct-fit. Designed in the USA with superior quality to the OEM.
